Màn hình ghép Christie 46 inch - FHD461-X

FHD461-X

Display

screen size (diagonal)

• 46" (1168.4mm)

native resolution

• 1920 x 1080 (16:9)

technology

• Commercial-grade LCD

backlight

• Direct LED

LED lifespan

• 50,000 hrs (50% brightness)

display orientation

• Landscape or portrait

pixel pitch

• 0.02 x 0.02" (0.53 x 0.53mm)

nominal bezel size

• 0.13" (3.4mm) (top/left) • 0.08" (2.0mm) (bottom/right)

brightness

• 700 nits (cd/m2) maximum • 500 nits (cd/m2) typical

contrast ratio (full field)

• 4000:1

viewing angle (CR 10:1)

• 178° h/v

refresh rate

• 50/60Hz

response time

• 6.5 ms

color space (CIE 1931)

• 72%

display colors

• 1.07 billion

Signal

inputs

• HDMI (HDCP) x2 • DVI (HDCP) • DisplayPort • VGA
• Component • S-Video • Composite • Audio L/R
• Audio 3.5mm • Infrared extender 3.5mm

outputs

• DVI (HDCP) • VGA • Audio 3.5mm

Control              inputs

• RS-232 • RS-485

outputs

• RS-485

Power

input rating

• 100-240 VAC @ 50/60Hz; 2A

power consumption

• 170W maximum • 105W typical • £0.5W standby

ENERGY STAR®

• 6.0

Environmental

operating temperature

• 41°-104°F (5°-40°C)

operating humidity

• 20-90% non-condensing

storage temperature

• -4°-41°F (-20°-60°C)

Physical

panel only

Dimensions (WxHxD)

Weight

• 40.31 x 22.77 x 3.08" (1023.8 x 578.4 x 78.2mm)

• 51lbs (23kg)

panel with

quick access mount1

• 40.31 x 22.77 x 6.15-6.90"

(1023.8 x 578.4 x 156.2-175.2mm)

• 99lbs (45kg)

panel with

thin profile mount1

• 40.31 x 22.77 x 3.78"

(1023.8 x 578.4 x 95.7mm)

• 64lbs (29kg)

panel mount locations

• VESA standard (WxH) 23.62 x 15.75" (600 x 400mm)

Runtime

• Designed for 24/7 operation2, featuring a reliable power supply and cooling system

Features

• Commercial-grade LCD • Anti-glare coating • Full HD resolution • Landscape or portrait

orientation • Front-accessible mount • Stackable frames and pedestals • Advanced cooling design • High energy efficiency with £0.5W standby • Plug and Play (DDC2B)

• Bezel compensation option • Image Retention Frame Motion (IRFM) mode • Auto Scan source selection • Aspect-ratio control • Zoom • Picture-in-Picture (PiP) • Advanced image settings
• Configurable power on delay • Sleep timer • Single DVI input can be shared by up to 3x3 panels
• Control up to 25 panels through single RS-232 and Video Wall Toolbox software on a remote PC
• Auto setup for single-input video wall • Control each panel with on-screen display (OSD) using infrared (IR) remote control

Accessories

• Panel ships with remote control, IR extender, DVI cable, Ethernet cable (RS-485) and RS-232 cable
• Regional power cord available separately • Quick access wall mounts: ML10 for landscape, MP10 for portrait, spacer kits available • Thin wall mount available from third party

Warranty

• Three years parts and labor limited warranty
• Contact an authorized Christie representative for full details of our limited warranty
